Product Details
Features
- Computer Numerical Control (CNC) from 8620 billet steel and case harden
- Designed and dyno proven in the USA
- Engineered by using valvetrain software
- Adds a 5%-10% power gain
- Select cams feature Hot Cams Improved Throttle Design (I.T.R.) technology; these cams improve throttle response throughout the entire rpm range while providing excellent power gains through the mid-range and top-end
- Designed for mid to top end gains.
- Engineered to be drop in cams that use stock valve springs (unless otherwise noted).
Specs
| Intake Duration | 265° |
| Intake Lobe Centerline | 107° |
| Riding Style | Off-Road |
| Application | Exhaust |
| Product Name | Camshaft |
| Type | Stage 2 |
| Intake Lift | 9.570 mm |
| Exhaust Duration | 260° |
| Exhaust Lift | 9.510 mm |
| Exhaust Lobe Centerline | 103° |
| Application | Intake |
| Units | Each |
Part Notes
- More top-end than Stage 1 with additional mid range gains.
- Uses stock valve springs and rockers.
- Does not use auto-decompression mechanism.
- For single cam engine.
- Intake Valve Lash: 0.150 mm.
- Exhaust Valve Lash: 0.200 mm.
Features
- Computer Numerical Control (CNC) from 8620 billet steel and case harden
- Designed and dyno proven in the USA
- Engineered by using valvetrain software
- Adds a 5%-10% power gain
- Select cams feature Hot Cams Improved Throttle Design (I.T.R.) technology; these cams improve throttle response throughout the entire rpm range while providing excellent power gains through the mid-range and top-end
- Designed for mid to top end gains.
- Engineered to be drop in cams that use stock valve springs (unless otherwise noted).
Specs
| Intake Duration | 265° |
| Intake Lobe Centerline | 107° |
| Riding Style | Off-Road |
| Application | Exhaust |
| Product Name | Camshaft |
| Type | Stage 2 |
| Intake Lift | 9.570 mm |
| Exhaust Duration | 260° |
| Exhaust Lift | 9.510 mm |
| Exhaust Lobe Centerline | 103° |
| Application | Intake |
| Units | Each |
Part Notes
- More top-end than Stage 1 with additional mid range gains.
- Uses stock valve springs and rockers.
- Does not use auto-decompression mechanism.
- For single cam engine.
- Intake Valve Lash: 0.150 mm.
- Exhaust Valve Lash: 0.200 mm.
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| XR650S2-A | 1010-2 | In Stock |
