Product Details
Features
- Designed and dyno proven in the USA
- Engineered by using valvetrain software
- Adds a 5%-10% power gain
- CNC machined from 8620 billet, case hardened steel for an exact fit and lobe profile
- Select cams feature Hot Cams Improved Throttle Design (I.T.R.) technology; these cams improve throttle response throughout the entire rpm range while providing excellent power gains through the mid-range and top-end
- Designed for low end torque.
- Engineered to be drop in cams that use stock valve springs (unless otherwise noted).
Specs
| Units | Each |
| Exhaust Lift | 8.710 mm |
| Exhaust Lobe Centerline | 104° |
| Product Name | Camshaft |
| Riding Style | Off-Road |
| Application | Exhaust |
| Exhaust Duration | 269° |
| Intake Duration | 248.700° |
| Intake Lobe Centerline | 101.850 mm |
| Application | Intake |
| Intake Lift | 10.080 mm |
| Type | Stage 1 |
Part Notes
- Improved torque below 8000 rpm with no loss in peak horsepower over OEM cam.
- Uses stock valve springs and rockers.
- Uses stock auto-decompression mechanism.
- For single cam engine.
- Intake Valve Lash: 0.160 mm.
- Exhaust Valve Lash: 0.280 mm.
Features
- Designed and dyno proven in the USA
- Engineered by using valvetrain software
- Adds a 5%-10% power gain
- CNC machined from 8620 billet, case hardened steel for an exact fit and lobe profile
- Select cams feature Hot Cams Improved Throttle Design (I.T.R.) technology; these cams improve throttle response throughout the entire rpm range while providing excellent power gains through the mid-range and top-end
- Designed for low end torque.
- Engineered to be drop in cams that use stock valve springs (unless otherwise noted).
Specs
| Units | Each |
| Exhaust Lift | 8.710 mm |
| Exhaust Lobe Centerline | 104° |
| Product Name | Camshaft |
| Riding Style | Off-Road |
| Application | Exhaust |
| Exhaust Duration | 269° |
| Intake Duration | 248.700° |
| Intake Lobe Centerline | 101.850 mm |
| Application | Intake |
| Intake Lift | 10.080 mm |
| Type | Stage 1 |
Part Notes
- Improved torque below 8000 rpm with no loss in peak horsepower over OEM cam.
- Uses stock valve springs and rockers.
- Uses stock auto-decompression mechanism.
- For single cam engine.
- Intake Valve Lash: 0.160 mm.
- Exhaust Valve Lash: 0.280 mm.
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| 0925-0843 | 1259-1 | In Stock |
This Product Fits
Fitment Disclosure
This quick reference fitment information is provided to direct you to our catalog information and the manufacturer's information. Consult manufacturer publication(s) and/or website(s) for specific fitment and application information and other important information. This fitment information is based upon the stock version of the motorcycle or unit referenced and any accessory added or other modification could invalidate the quick reference information provided.
