Availability:
10 in stock, ready to be shipped
Six times harder than platinum, iridium withstands temperatures up to 4,000°F
Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
360° laser welding of electrode provides a seal that resists wear even in the worst conditions
Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
Terminal Configuration
Threaded Stud
Units
Each
Center Electrode Projection
Non-Projected
Hex Size
20.6 mm
Ground Electrode Shape
Taper Cut
Product Name
Spark Plug
Riding Style
Street
Style
Iridium
Electrical Resistance
5k Ohms
Thread Reach
19.1 mm
Ground Electrode Shape
Grooved
Spark Gap
0.8 mm
Type
Resistor
Center Electrode Type
Fine Wire
Model
IW22
Spark Gap
0.031"
Electrode Tip Material
Iridium
Heat Range
7
Original price
$15.95
-
Original price
$15.95
Original price
$15.95
$15.95
-
$15.95
Current price
$15.95
Product Details
Features
- Six times harder than platinum, iridium withstands temperatures up to 4,000°F
- Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
- 360° laser welding of electrode provides a seal that resists wear even in the worst conditions
- Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
| Terminal Configuration | Threaded Stud |
| Units | Each |
| Center Electrode Projection | Non-Projected |
| Hex Size | 20.6 mm |
| Ground Electrode Shape | Taper Cut |
| Product Name | Spark Plug |
| Riding Style | Street |
| Style | Iridium |
| Electrical Resistance | 5k Ohms |
| Thread Reach | 19.1 mm |
| Ground Electrode Shape | Grooved |
| Spark Gap | 0.8 mm |
| Type | Resistor |
| Center Electrode Type | Fine Wire |
| Model | IW22 |
| Spark Gap | 0.031" |
| Electrode Tip Material | Iridium |
| Heat Range | 7 |
Features
- Six times harder than platinum, iridium withstands temperatures up to 4,000°F
- Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
- 360° laser welding of electrode provides a seal that resists wear even in the worst conditions
- Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
| Terminal Configuration | Threaded Stud |
| Units | Each |
| Center Electrode Projection | Non-Projected |
| Hex Size | 20.6 mm |
| Ground Electrode Shape | Taper Cut |
| Product Name | Spark Plug |
| Riding Style | Street |
| Style | Iridium |
| Electrical Resistance | 5k Ohms |
| Thread Reach | 19.1 mm |
| Ground Electrode Shape | Grooved |
| Spark Gap | 0.8 mm |
| Type | Resistor |
| Center Electrode Type | Fine Wire |
| Model | IW22 |
| Spark Gap | 0.031" |
| Electrode Tip Material | Iridium |
| Heat Range | 7 |
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| IW22 | 5307 | In Stock |
Product Description
Features
- Six times harder than platinum, iridium withstands temperatures up to 4,000°F
- Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
- 360° laser welding of electrode provides a seal that resists wear even in the worst conditions
- Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
| Terminal Configuration | Threaded Stud |
| Units | Each |
| Center Electrode Projection | Non-Projected |
| Hex Size | 20.6 mm |
| Ground Electrode Shape | Taper Cut |
| Product Name | Spark Plug |
| Riding Style | Street |
| Style | Iridium |
| Electrical Resistance | 5k Ohms |
| Thread Reach | 19.1 mm |
| Ground Electrode Shape | Grooved |
| Spark Gap | 0.8 mm |
| Type | Resistor |
| Center Electrode Type | Fine Wire |
| Model | IW22 |
| Spark Gap | 0.031" |
| Electrode Tip Material | Iridium |
| Heat Range | 7 |
Part Numbers
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| IW22 | 5307 | In Stock |
