Availability:
Out of stock
Six times harder than platinum, iridium withstands temperatures up to 4,000°F
Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
360° laser welding of electrode provides a seal that resists wear even in the worst conditions
Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
Thread Reach
19.1 mm
Center Electrode Projection
Non-Projected
Center Electrode Type
Fine Wire
Units
Each
Heat Range
31
Spark Gap
0.035"
Electrode Tip Material
Iridium
Ground Electrode Shape
Angled
Riding Style
Street
Spark Gap
0.9 mm
Model
IU31A
Hex Size
16 mm
Terminal Configuration
Threaded Stud
Electrical Resistance
5k Ohms
Ground Electrode Shape
Grooved
Product Name
Spark Plug
Style
Iridium
Type
Resistor
Sold out
Original price
$27.95
-
Original price
$27.95
Original price
$27.95
$27.95
-
$27.95
Current price
$27.95
Product Details
Features
- Six times harder than platinum, iridium withstands temperatures up to 4,000°F
- Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
- 360° laser welding of electrode provides a seal that resists wear even in the worst conditions
- Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
| Thread Reach | 19.1 mm |
| Center Electrode Projection | Non-Projected |
| Center Electrode Type | Fine Wire |
| Units | Each |
| Heat Range | 31 |
| Spark Gap | 0.035" |
| Electrode Tip Material | Iridium |
| Ground Electrode Shape | Angled |
| Riding Style | Street |
| Spark Gap | 0.9 mm |
| Model | IU31A |
| Hex Size | 16 mm |
| Terminal Configuration | Threaded Stud |
| Electrical Resistance | 5k Ohms |
| Ground Electrode Shape | Grooved |
| Product Name | Spark Plug |
| Style | Iridium |
| Type | Resistor |
Product Description
Features
- Six times harder than platinum, iridium withstands temperatures up to 4,000°F
- Because the iridium electrodes of these plugs can be shrunk to only 0.4mm, voltage requirements decrease while firing performance improves
- 360° laser welding of electrode provides a seal that resists wear even in the worst conditions
- Ground electrode features a tapered cut and U-groove that form a large volume area for the flame's center
Specs
| Thread Reach | 19.1 mm |
| Center Electrode Projection | Non-Projected |
| Center Electrode Type | Fine Wire |
| Units | Each |
| Heat Range | 31 |
| Spark Gap | 0.035" |
| Electrode Tip Material | Iridium |
| Ground Electrode Shape | Angled |
| Riding Style | Street |
| Spark Gap | 0.9 mm |
| Model | IU31A |
| Hex Size | 16 mm |
| Terminal Configuration | Threaded Stud |
| Electrical Resistance | 5k Ohms |
| Ground Electrode Shape | Grooved |
| Product Name | Spark Plug |
| Style | Iridium |
| Type | Resistor |
Part Numbers
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| IU31A | 5367 | Out of Stock |
