Availability:
Out of stock
Manufactured with the help of a computer with cam design capabilities
Made from alloy steel billets and heat-treated processes are utilized
Made in the USA
Installer must check coil bind, valve-to-valve clearance and valve-to-piston clearance.
'00-'06 model cams use a splined cam drive sprocket, for '99 a splined cam drive sprocket is required.
Specs
Exhaust Lift
0.560"
Intake Duration
260°
Application
Intake
Exhaust Lobe Centerline
108°
Product Name
Cam Set
Intake Close
56°
Intake Lift at TDC
0.205"
Exhaust Duration
260°
Intake Lift
0.560"
Intake Lobe Centerline
106°
Units
Pair
Exhaust Close
22°
Exhaust Open
58°
Riding Style
Street
Type
Chain Drive
Application
Exhaust
Exhaust Lift at TDC
0.192"
Grind
60 Series
Intake Open
24°
Part Notes
Designed for 95"+ motors with major head work.
Maximum torque and horsepower at middle and upper ranges from 2700 to 6500+ rpm.
Coil bind and valve-to-valve and valve-to-piston clearance must be checked.
Includes front cam support plate bearing.
'99 Twin Cam requires a splined cam drive sprocket.
Sold out
Original price
$415.95
-
Original price
$415.95
Original price
$415.95
$415.95
-
$415.95
Current price
$415.95
Product Details
Features
- Manufactured with the help of a computer with cam design capabilities
- Made from alloy steel billets and heat-treated processes are utilized
- Made in the USA
- Installer must check coil bind, valve-to-valve clearance and valve-to-piston clearance.
- '00-'06 model cams use a splined cam drive sprocket, for '99 a splined cam drive sprocket is required.
Specs
| Exhaust Lift | 0.560" |
| Intake Duration | 260° |
| Application | Intake |
| Exhaust Lobe Centerline | 108° |
| Product Name | Cam Set |
| Intake Close | 56° |
| Intake Lift at TDC | 0.205" |
| Exhaust Duration | 260° |
| Intake Lift | 0.560" |
| Intake Lobe Centerline | 106° |
| Units | Pair |
| Exhaust Close | 22° |
| Exhaust Open | 58° |
| Riding Style | Street |
| Type | Chain Drive |
| Application | Exhaust |
| Exhaust Lift at TDC | 0.192" |
| Grind | 60 Series |
| Intake Open | 24° |
Part Notes
- Designed for 95"+ motors with major head work.
- Maximum torque and horsepower at middle and upper ranges from 2700 to 6500+ rpm.
- Coil bind and valve-to-valve and valve-to-piston clearance must be checked.
- Includes front cam support plate bearing.
- '99 Twin Cam requires a splined cam drive sprocket.
Features
- Manufactured with the help of a computer with cam design capabilities
- Made from alloy steel billets and heat-treated processes are utilized
- Made in the USA
- Installer must check coil bind, valve-to-valve clearance and valve-to-piston clearance.
- '00-'06 model cams use a splined cam drive sprocket, for '99 a splined cam drive sprocket is required.
Specs
| Exhaust Lift | 0.560" |
| Intake Duration | 260° |
| Application | Intake |
| Exhaust Lobe Centerline | 108° |
| Product Name | Cam Set |
| Intake Close | 56° |
| Intake Lift at TDC | 0.205" |
| Exhaust Duration | 260° |
| Intake Lift | 0.560" |
| Intake Lobe Centerline | 106° |
| Units | Pair |
| Exhaust Close | 22° |
| Exhaust Open | 58° |
| Riding Style | Street |
| Type | Chain Drive |
| Application | Exhaust |
| Exhaust Lift at TDC | 0.192" |
| Grind | 60 Series |
| Intake Open | 24° |
Part Notes
- Designed for 95"+ motors with major head work.
- Maximum torque and horsepower at middle and upper ranges from 2700 to 6500+ rpm.
- Coil bind and valve-to-valve and valve-to-piston clearance must be checked.
- Includes front cam support plate bearing.
- '99 Twin Cam requires a splined cam drive sprocket.
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| DS-199182 | 288160 | Out of Stock |
This product is vehicle specific.
Select your vehicle to confirm fitment.
This Product Fits
Fitment Disclosure
This quick reference fitment information is provided to direct you to our catalog information and the manufacturer's information. Consult manufacturer publication(s) and/or website(s) for specific fitment and application information and other important information. This fitment information is based upon the stock version of the motorcycle or unit referenced and any accessory added or other modification could invalidate the quick reference information provided.
Product Description
Features
- Manufactured with the help of a computer with cam design capabilities
- Made from alloy steel billets and heat-treated processes are utilized
- Made in the USA
- Installer must check coil bind, valve-to-valve clearance and valve-to-piston clearance.
- '00-'06 model cams use a splined cam drive sprocket, for '99 a splined cam drive sprocket is required.
Specs
| Exhaust Lift | 0.560" |
| Intake Duration | 260° |
| Application | Intake |
| Exhaust Lobe Centerline | 108° |
| Product Name | Cam Set |
| Intake Close | 56° |
| Intake Lift at TDC | 0.205" |
| Exhaust Duration | 260° |
| Intake Lift | 0.560" |
| Intake Lobe Centerline | 106° |
| Units | Pair |
| Exhaust Close | 22° |
| Exhaust Open | 58° |
| Riding Style | Street |
| Type | Chain Drive |
| Application | Exhaust |
| Exhaust Lift at TDC | 0.192" |
| Grind | 60 Series |
| Intake Open | 24° |
Part Notes
- Designed for 95"+ motors with major head work.
- Maximum torque and horsepower at middle and upper ranges from 2700 to 6500+ rpm.
- Coil bind and valve-to-valve and valve-to-piston clearance must be checked.
- Includes front cam support plate bearing.
- '99 Twin Cam requires a splined cam drive sprocket.
Part Numbers
| Store SKU | MFR. Product # | Availability |
|---|---|---|
| DS-199182 | 288160 | Out of Stock |
Fitment
This product is vehicle specific.
Select your vehicle to confirm fitment.
This Product Fits
Fitment Disclosure
This quick reference fitment information is provided to direct you to our catalog information and the manufacturer's information. Consult manufacturer publication(s) and/or website(s) for specific fitment and application information and other important information. This fitment information is based upon the stock version of the motorcycle or unit referenced and any accessory added or other modification could invalidate the quick reference information provided.
